iiyama 15.6” Full HD PCAP 10pt touchscreen monitor with IPS panel technology, integrated media player and a hinged stand on the back

SKU

T1624MSC-B1

Skip to the beginning of the images gallery

In Stock: 7 available

15.6” Full HD PCAP 10pt touchscreen monitor with IPS panel technology, integrated media player and a hinged stand on the back

Category: Signage Displays

More Information

More Information
HD type	Full HD
Display Technology	LCD
Display brightness	450cd/m²
Product design	Interactive flat panel
SKU	T1624MSC-B1
EAN	4948570120451
Manufacturer	iiyama
Availability	Out of Stock
PDF URLs	View PDF View PDF View PDF View PDF View PDF

Reasons To Buy

Touch technology - Capacitive

This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.

Media player

Play your favourite music and show your most beautiful videos, photos and images directly on screen from a flash drive or internal memory with the built-in media player.

IPS Technology

IPS displays are best known for wide viewing angles and natural, highly accurate colours. They are especially suited for colour-critical applications.

Full HD

With true 1920 x 1080p resolution your monitor is ready to display high definition images. This means you can accommodate more information on your screen; e.g. 60% more in comparison to a 1280 x 1024 monitor.

Speakers

This LED monitor is equipped with two high quality stereo speakers.

Description

With 1920x1080 Full HD resolution and Projective Capacitive 10 point touch technology, the ProLite T1624MSC delivers seamless and accurate touch response. Featuring IPS Panel technology, it offers exceptional colour performance and wide viewing angles, making it an excellent choice for a vast array of demanding interactive applications. Users can benefit from its hinged stand allowing the monitor to lay down completely flat for use as a tablet. The T1624MSC comes equipped with several inputs and a SD card slot, as well as stereo speakers delivering good quality sound. An ideal screen for small interactive Digital Signage, InStore Retail and interactive presentations purposes.

Specifications

Display
LED backlight	Yes
Panel type	IPS
Display number of colours	16.7 million colours
Number of simultaneous touchpoints	10
Touchscreen	Yes
Active display area (W x H)	344.16 x 193.59 mm
Display technology	LCD
Display diagonal	39.6 cm (15.6")
Display resolution	1920 x 1080 pixels
Display brightness	450 cd/m²
HD type	Full HD
Response time	25 ms
Contrast ratio (typical)	800:1
Viewing angle, horizontal	170°
Viewing angle, vertical	170°
Pixel pitch	0.17925 x 0.17925 mm
Display diagonal (metric)	39.5 cm
Native aspect ratio	16:9
Horizontal scan range	30 - 84 kHz
Touchscreen technology	Projected capacitive system
Surface hardness	6H
Ports & interfaces
USB port	Yes
Wi-Fi	No
PC Audio in	Yes
DisplayPorts quantity	0
Ethernet LAN	No
HDMI ports quantity	1
DVI port	No
USB version	2.0
USB ports quantity	2
HDMI input ports quantity	1
Audio
Number of built-in speakers	2
RMS rated power	4 W
Built-in speaker(s)	Yes
Design
Product design	Interactive flat panel
Product colour	Black
Panel mounting interface	100 x 100 mm
VESA mounting	Yes
Screen shape	Flat
Performance
Purpose	Universal
Operating hours (hours/days)	24/7
Wi-Fi	No
Power
Power consumption (off)	0.1 W
Power consumption (typical)	7 W
Power consumption (standby)	0.5 W
Energy efficiency scale	A to G
Input voltage	12 V
Energy efficiency class (SDR)	E
Energy consumption (SDR) per 1000 hours	11 kWh

Computer system
Computer system	No
Built-in processor	No
Weight & dimensions
Width (with stand)	388 mm
Height (with stand)	245 mm
Depth (with stand)	159.5 mm
Weight (with stand)	2.6 kg
Display width	388 mm
Display depth	159.5 mm
Display height	245 mm
Display weight	2.6 kg
Packaging content
Cables included	AC, HDMI, USB
Technical details
VESA mounting	Yes
Panel type	IPS
Number of simultaneous touchpoints	10
Weight (with stand)	2.6 kg
Sustainability certificates	ErP
Compliance certificates	CE, REACH, RoHS, WEEE
Packaging data
Cables included	AC, HDMI, USB
Other features
Panel type	IPS
Number of simultaneous touchpoints	10
Wi-Fi	No
Width (with stand)	388 mm
Height (with stand)	245 mm
Display technology	LCD
Depth (with stand)	159.5 mm
Built-in camera	No
Audio input	Yes
Weight (with stand)	2.6 kg
Energy efficiency scale	A to G
Input voltage	12 V
