iiyama 21.5” Full HD PCAP 10pt interactive Touch Panel PC with Android OS and edge-to-edge glass design

SKU

TW2223AS-B2

Skip to the end of the images gallery

Skip to the beginning of the images gallery

In Stock: 8 available

21.5” Full HD PCAP 10pt interactive Touch Panel PC with Android OS and edge-to-edge glass design

Category: Signage Displays

More Information

More Information
HD type	Full HD
Display brightness	400cd/m²
Product design	Interactive flat panel
SKU	TW2223AS-B2
EAN	4948570124787
Manufacturer	iiyama
Availability	In Stock
PDF URLs	View PDF View PDF

Reasons To Buy

Touch technology - Capacitive

This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.

Android OS

Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.

Full HD

With true 1920 x 1080p resolution your monitor is ready to display high definition images. This means you can accommodate more information on your screen; e.g. 60% more in comparison to a 1280 x 1024 monitor.

24/7

24/7 displays are designed for a continuous operation.

Speakers

This LED monitor is equipped with two high quality stereo speakers.

Description

The ProLite TW2223AS-B2 interactive Touch Panel PC with an elegant edge-to-edge glass design is a perfect choice for high-use environments. This monitor can operate 24/7 in landscape, portrait and face-up orientation. Thanks to the pre-installed Android 12 operating system it is possible to easily customize the monitor by installing applications directly to it. In combination with the 32GB storage, Wi-Fi connection, LAN (RJ45) and Bluetooth connectors, it makes the monitor especially suited for POS systems or information points in retail shops to educate customers about your products, as well as virtually limitless smart home applications.

Specifications

Display
Panel type	VA
Display number of colours	16.7 million colours
Number of simultaneous touchpoints	10
Touchscreen	Yes
Active display area (W x H)	478 x 269.5 mm
Display diagonal	54.6 cm (21.5")
Display resolution	1920 x 1080 pixels
Display brightness	400 cd/m²
HD type	Full HD
Response time	18 ms
Contrast ratio (typical)	3000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Pixel pitch	0.248 x 0.248 mm
Display diagonal (metric)	54.6 cm
Native aspect ratio	16:9
Horizontal scan range	30 - 84 kHz
Touchscreen technology	Projected capacitive system
Surface hardness	6H
Glass thickness	2.9 mm
Ports & interfaces
USB port	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi	Yes
Ethernet LAN	Yes
HDMI ports quantity	1
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB ports quantity	5
Audio
Number of built-in speakers	2
RMS rated power	4 W
Built-in speaker(s)	Yes
Design
Product design	Interactive flat panel
Placement supported	Indoor
Orientation	Horizontal/Vertical
Product colour	Black
Panel mounting interface	100 x 100 mm
Certification	CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA
VESA mounting	Yes
Screen shape	Flat
Performance
Purpose	Universal
Operating hours (hours/days)	24/7
Mean time between failures (MTBF)	50000 h
HDCP	Yes
Wi-Fi	Yes
Power
Power consumption (off)	0.3 W
Power consumption (typical)	23 W
Power consumption (standby)	0.5 W
Computer system
Computer system	Yes
Processor cores	2
Processor family	ARM Rockchip
Processor frequency	1.8 GHz
Operating system installed	Android 12
Internal memory	4 GB
Internal storage capacity	32 GB
Built-in processor	Yes
On-board graphics card model	A72 + A53

Weight & dimensions
Display width	504.5 mm
Display depth	32 mm
Display height	302 mm
Display weight	3.61 kg
Packaging data
Package width	640 mm
Package depth	121 mm
Package height	410 mm
Package weight	5.98 kg
Cables included	AC
Packaging content
Cables included	AC
Certificates
Certification	CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA
Technical details
VESA mounting	Yes
Panel type	VA
Number of simultaneous touchpoints	10
Audio out (mini jack)	1
Thin Client
Processor family	ARM Rockchip
Processor frequency	1.8 GHz
Operating system installed	Android 12
Internal memory	4 GB
Internal storage capacity	32 GB
Other features
Panel type	VA
Number of simultaneous touchpoints	10
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi	Yes
Mean time between failures (MTBF)	50000 h
Bluetooth version	5.2
Bluetooth	Yes
