iiyama 23.8” Full HD In-cell PCAP 10pt interactive Touch Panel PC with Android OS, IPS panel technology and anti glare coating
SKU
TW2424AS-B1
Login for pricing
In Stock:
24 available
23.8” Full HD In-cell PCAP 10pt interactive Touch Panel PC with Android OS, IPS panel technology and anti glare coating
Category: Signage Displays
Android OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.
Touch technology - Capacitive
This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.
IPS
IPS displays are best known for wide viewing angles and natural, highly accurate colours. They are especially suited for colour-critical applications.
24/7
24/7 displays are designed for a continuous operation.
Speakers and headphones
Playing with friends? Use the integrated high-quality speakers. Don’t want to disturb anybody? Plug your headset into the headphone socket and turn the volume up.
The ProLite TW2424AS-B1 interactive Touchpanel-PC is a perfect choice for high-use environments. The IPS panel, integrated in a slim and elegant bezel, delivers both excellent colour performance with wide viewing angles and noticeably sharper images. The In-cell 10tp PCAP touch technology ensures a fluid and natural touch experience. This monitor can operate in landscape, portrait and face-up orientation in 24/7 operating time. Thanks to the pre-installed Android 12 operating system, it is possible to easily customize the monitor by installing applications directly to it. In combination with the 32GB storage, Wi-Fi connection, LAN (RJ45) and Bluetooth connectors, it makes the monitor especially suited for POS systems or information points in retail shops to educate customers about your products, as well as virtually limitless smart home applications.
| Display | |
|---|---|
| Panel type | IPS |
| Display number of colours | 16.7 million colours |
| Number of simultaneous touchpoints | 10 |
| LED backlighting type | Direct-LED |
| Touchscreen | Yes |
| Active display area (W x H) | 527 x 296.5 mm |
| Display diagonal | 60.5 cm (23.8") |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 250 cd/m² |
| HD type | 4K Ultra HD |
| Response time | 14 ms |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.275 x 0.275 mm |
| Display diagonal (metric) | 60.5 cm |
| Panel life | 50000 h |
| Native aspect ratio | 16:9 |
| Horizontal scan range | 31 - 83 kHz |
| Anti-glare screen | Yes |
| Touchscreen technology | Projected capacitive system |
| Surface hardness | 3H |
| Ports & interfaces | |
| USB port | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| HDMI ports quantity | 1 |
| VGA (D-Sub) input ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI input ports quantity | 1 |
| USB 2.0 Type-B ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Audio | |
| Number of built-in speakers | 2 |
| RMS rated power | 5 W |
| Built-in speaker(s) | Yes |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Product colour | Black |
| Panel mounting interface | 100 x 100 mm |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| VESA mounting | Yes |
| Anti-glare screen | Yes |
| Performance | |
| Purpose | Commercial |
| Operating hours (hours/days) | 24/7 |
| Mean time between failures (MTBF) | 50000 h |
| On Screen Display (OSD) | Yes |
| HDCP | Yes |
| Plug and Play | Yes |
| Wi-Fi | Yes |
| Panel life | 50000 h |
| Power | |
| Power consumption (off) | 0.3 W |
| Power consumption (typical) | 19 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Computer system | |
| Computer system | Yes |
| Processor cores | 2 |
| Processor family | ARM Rockchip |
| Processor model | RK3399 |
| Processor frequency | 1.8 GHz |
| Operating system installed | Android |
| Internal memory | 4 GB |
| Internal storage capacity | 32 GB |
| Processor manufacturer | Rockchip |
| Built-in processor | Yes |
| Operating system version | 12 |
| Weight & dimensions | |
|---|---|
| Display width | 549.5 mm |
| Display depth | 28 mm |
| Display height | 336 mm |
| Display weight | 4.23 kg |
| Packaging data | |
| Package width | 580 mm |
| Package depth | 126 mm |
| Package height | 375 mm |
| Package weight | 6.15 kg |
| Quick start guide | Yes |
| Batteries included | Yes |
| Remote control included | Yes |
| Cables included | HDMI, Power, USB |
| Stylus pen | Yes |
| Number of stylus pens | 4 |
| Packaging content | |
| Quick start guide | Yes |
| Batteries included | Yes |
| Remote control included | Yes |
| Cables included | HDMI, Power, USB |
| Stylus pen | Yes |
| Number of stylus pens | 4 |
| Certificates | |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| Technical details | |
| VESA mounting | Yes |
| Power supply type | Internal |
| Panel type | IPS |
| Number of simultaneous touchpoints | 10 |
| LED backlighting type | Direct-LED |
| OPS slot | 1 |
| Thin Client | |
| Processor family | ARM Rockchip |
| Processor model | RK3399 |
| Processor frequency | 1.8 GHz |
| Operating system installed | Android |
| Internal memory | 4 GB |
| Internal storage capacity | 32 GB |
| Features | |
| Base colour | Black |
| Base material | Metal |
| Suitable for indoor use | Yes |
| Other features | |
| Power supply type | Internal |
| Panel type | IPS |
| Number of simultaneous touchpoints | 10 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| Mean time between failures (MTBF) | 50000 h |
| Bluetooth version | 5.2 |
| Bluetooth | Yes |
| Quick start guide | Yes |
| Plug and Play | Yes |
| Bluetooth Low Energy (BLE) | Yes |
| Stylus pen | Yes |
| Number of stylus pens | 4 |
